S800 Analog Input Variants
Item No:
S830-14C02CV04G04GIND
16 Channel Analog Output Module
AI_Varaiant
AIS830-14C02CV04G04GIND
AIS830-12C04CV04G04GIND
AIS830-16C00CV04G04GIND
No. of Analog Input
16 Channels
Type Of Analog Input
14 Channels 4-20mA
2 Channels 0-20 mA OR 0-10VDC Selectable
12 Channels 4-20mA
4 Channels 4-20 mA OR 0-10VDC Selectable
16 Channels 0-20mA
Hardware Functional Status
From Jul22
Firmware Version
1.00.001
Firmware Update Possible
Yes
Engineering Software
Codesys V3 5 Sp 19 And Above
Mounting
Base Unit Tbus Pppppppp
| AI_Varaiant | AIS830-14C02CV04G04GIND | AIS830-12C04CV04G04GIND | AIS830-16C00CV04G04GIND |
| No. of Analog Input | 16 Channels | ||
| Type Of Analog Input | 14 Channels 4-20mA 2 Channels 0-20 mA OR 0-10VDC Selectable |
12 Channels 4-20mA 4 Channels 4-20 mA OR 0-10VDC Selectable |
16 Channels 0-20mA |
| Hardware Functional Status | From Jul22 | ||
| Firmware Version | 1.00.001 | ||
| Firmware Update Possible | Yes | ||
| Engineering Software | Codesys V3 5 Sp 19 And Above | ||
| Mounting | Base Unit Tbus Pppppppp | ||
AI_Varaiant
AIS830-14C02CV04G04GIND
AIS830-12C04CV04G04GIND
AIS830-16C00CV04G04GIND
Galvanic Isolation
Yes
Galvanic Isolation Group
04
Channel In Group
04
| AI_Varaiant | AIS830-14C02CV04G04GIND | AIS830-12C04CV04G04GIND | AIS830-16C00CV04G04GIND |
| Galvanic Isolation | Yes | ||
| Galvanic Isolation Group | 04 | ||
| Channel In Group | 04 | ||
AI_Varaiant
AIS830-14C02CV04G04GIND
AIS830-12C04CV04G04GIND
AIS830-16C00CV04G04GIND
Power Supply From
Top Side De Coded Plug In Screw Terminal
Normal Supply Voltage
24 Vdc
Low Supply Voltage
18.5 Vdc
High Sypply Voltage
28.5
Reverse Polarity Protection
Yes
Input Current
0.4 AMP
Input Current Per Channel Permissible
21.5 mA
Transmitter Power
Yes
Power Loss
0.245 W
| AI_Varaiant | AIS830-14C02CV04G04GIND | AIS830-12C04CV04G04GIND | AIS830-16C00CV04G04GIND |
| Power Supply From | Top Side De Coded Plug In Screw Terminal | ||
| Normal Supply Voltage | 24 Vdc | ||
| Low Supply Voltage | 18.5 Vdc | ||
| High Sypply Voltage | 28.5 | ||
| Reverse Polarity Protection | Yes | ||
| Input Current | 0.4 AMP | ||
| Input Current Per Channel Permissible | 21.5 mA | ||
| Transmitter Power | Yes | ||
| Power Loss | 0.245 W | ||
AI_Varaiant
AIS830-14C02CV04G04GIND
AIS830-12C04CV04G04GIND
AIS830-16C00CV04G04GIND
Input Range
0-20 mA
Input Range
4-20 mA
Input Range
-
0-10 mA
-
Mesasurning Range
Scalable
Input Resistance
120 Ω
| AI_Varaiant | AIS830-14C02CV04G04GIND | AIS830-12C04CV04G04GIND | AIS830-16C00CV04G04GIND |
| Input Range | 0-20 mA | ||
| Input Range | 4-20 mA | ||
| Input Range | - | 0-10 mA | - |
| Mesasurning Range | Scalable | ||
| Input Resistance | 120 Ω | ||
AI_Varaiant
AIS830-14C02CV04G04GIND
AIS830-12C04CV04G04GIND
AIS830-16C00CV04G04GIND
Perameterization In Run
Yes
Calibration In Run
Yes
| AI_Varaiant | AIS830-14C02CV04G04GIND | AIS830-12C04CV04G04GIND | AIS830-16C00CV04G04GIND |
| Perameterization In Run | Yes | ||
| Calibration In Run | Yes | ||
AI_Varaiant
AIS830-14C02CV04G04GIND
AIS830-12C04CV04G04GIND
AIS830-16C00CV04G04GIND
Automatic Encoding
No
Mechanical Coding Element
Yes
| AI_Varaiant | AIS830-14C02CV04G04GIND | AIS830-12C04CV04G04GIND | AIS830-16C00CV04G04GIND |
| Automatic Encoding | No | ||
| Mechanical Coding Element | Yes | ||
AI_Varaiant
AIS830-14C02CV04G04GIND
AIS830-12C04CV04G04GIND
AIS830-16C00CV04G04GIND
Analog Input Measuring Principal
Sigma Delta Integrating
| AI_Varaiant | AIS830-14C02CV04G04GIND | AIS830-12C04CV04G04GIND | AIS830-16C00CV04G04GIND |
| Analog Input Measuring Principal | Sigma Delta Integrating | ||
AI_Varaiant
AIS830-14C02CV04G04GIND
AIS830-12C04CV04G04GIND
AIS830-16C00CV04G04GIND
Resolution With Over Range Max
12 Bit
Conversion Time Per Chennal
100 Ms
| AI_Varaiant | AIS830-14C02CV04G04GIND | AIS830-12C04CV04G04GIND | AIS830-16C00CV04G04GIND |
| Resolution With Over Range Max | 12 Bit | ||
| Conversion Time Per Chennal | 100 Ms | ||
AI_Varaiant
AIS830-14C02CV04G04GIND
AIS830-12C04CV04G04GIND
AIS830-16C00CV04G04GIND
Linearity Error
0.1% (Input Range)
Operational Error
0.5% (Input Range)
Basic Error
0.3% (Input Range)
| AI_Varaiant | AIS830-14C02CV04G04GIND | AIS830-12C04CV04G04GIND | AIS830-16C00CV04G04GIND |
| Linearity Error | 0.1% (Input Range) | ||
| Operational Error | 0.5% (Input Range) | ||
| Basic Error | 0.3% (Input Range) | ||
AI_Varaiant
AIS830-14C02CV04G04GIND
AIS830-12C04CV04G04GIND
AIS830-16C00CV04G04GIND
Series Mode Interference
Min 70dB
Common Mode Voltage
Max 10 V
Common Mode Interference
90 dB
| AI_Varaiant | AIS830-14C02CV04G04GIND | AIS830-12C04CV04G04GIND | AIS830-16C00CV04G04GIND |
| Series Mode Interference | Min 70dB | ||
| Common Mode Voltage | Max 10 V | ||
| Common Mode Interference | 90 dB | ||
AI_Varaiant
AIS830-14C02CV04G04GIND
AIS830-12C04CV04G04GIND
AIS830-16C00CV04G04GIND
Diagnostics Alarm
Yes
Limit Alarm
Yes
| AI_Varaiant | AIS830-14C02CV04G04GIND | AIS830-12C04CV04G04GIND | AIS830-16C00CV04G04GIND |
| Diagnostics Alarm | Yes | ||
| Limit Alarm | Yes | ||
AI_Varaiant
AIS830-14C02CV04G04GIND
AIS830-12C04CV04G04GIND
AIS830-16C00CV04G04GIND
Wire-Break
Yes(4-20mA)
Short Circuit
Yes
Channel Diagnostic
Yes
| AI_Varaiant | AIS830-14C02CV04G04GIND | AIS830-12C04CV04G04GIND | AIS830-16C00CV04G04GIND |
| Wire-Break | Yes(4-20mA) | ||
| Short Circuit | Yes | ||
| Channel Diagnostic | Yes | ||
AI_Varaiant
AIS830-14C02CV04G04GIND
AIS830-12C04CV04G04GIND
AIS830-16C00CV04G04GIND
Power Of Indication
Yes
Channel Status
No
Channel Diagnostics(Wire Break Joint)
No
Module Diagnostics (Back Plan Comm)
Yes
| AI_Varaiant | AIS830-14C02CV04G04GIND | AIS830-12C04CV04G04GIND | AIS830-16C00CV04G04GIND | |
| Power Of Indication | Yes | |||
| Channel Status | No | |||
| Channel Diagnostics(Wire Break Joint) | No | |||
| Module Diagnostics (Back Plan Comm) | Yes | |||
AI_Varaiant
AIS830-14C02CV04G04GIND
AIS830-12C04CV04G04GIND
AIS830-16C00CV04G04GIND
Seperation Between Channel
Yes
Seperation Between Backplane
Yes
Seperation Between Channel And System Power Supply
Yes
Insulation Tested With
500 VDC
| AI_Varaiant | AIS830-14C02CV04G04GIND | AIS830-12C04CV04G04GIND | AIS830-16C00CV04G04GIND | |
| Seperation Between Channel | Yes | |||
| Seperation Between Backplane | Yes | |||
| Seperation Between Channel And System Power Supply | Yes | |||
| Insulation Tested With | 500 VDC | |||
AI_Varaiant
AIS830-14C02CV04G04GIND
AIS830-12C04CV04G04GIND
AIS830-16C00CV04G04GIND
Horizontal Installation
Min 0 Degree Celcius
Horizontal Installation
Max 60 Degree Celcius
Vertical Installation
Min 0 Degree Celcius
Vertical Installation
Max 60 Degree Celcius
| AI_Varaiant | AIS830-14C02CV04G04GIND | AIS830-12C04CV04G04GIND | AIS830-16C00CV04G04GIND | |
| Horizontal Installation | Min 0 Degree Celcius | |||
| Horizontal Installation | Max 60 Degree Celcius | |||
| Vertical Installation | Min 0 Degree Celcius | |||
| Vertical Installation | Max 60 Degree Celcius | |||
AI_Varaiant
AIS830-14C02CV04G04GIND
AIS830-12C04CV04G04GIND
AIS830-16C00CV04G04GIND
Field Connection
37 Pin D_Sub Connector
Power Connection
5 Pin Pheonix Plug In Connector (D-Coded)
| AI_Varaiant | AIS830-14C02CV04G04GIND | AIS830-12C04CV04G04GIND | AIS830-16C00CV04G04GIND |
| Field Connection | 37 Pin D_Sub Connector | ||
| Power Connection | 5 Pin Pheonix Plug In Connector (D-Coded) | ||
AI_Varaiant
AIS830-14C02CV04G04GIND
AIS830-12C04CV04G04GIND
AIS830-16C00CV04G04GIND
Cable Length Max.
500 MTR. Max Of 1.0 SQMM Cable, Shielded
Address Space Per Module
32 Bytes
Dimention (W x H x D)
25 x 122 x 115
Weight
160g Approx
| AI_Varaiant | AIS830-14C02CV04G04GIND | AIS830-12C04CV04G04GIND | AIS830-16C00CV04G04GIND | |
| Cable Length Max. | 500 MTR. Max Of 1.0 SQMM Cable, Shielded | |||
| Address Space Per Module | 32 Bytes | |||
| Dimention (W x H x D) | 25 x 122 x 115 | |||
| Weight | 160g Approx | |||
The Analog Input Module Is A Crucial Component Designed To Facilitate The Integration Of Analog Signals Into The Plc System It Receives Analog Signals From A Diverse Array Of External Devices Including Sensors Transmitters Gauges Variable Frequency Drives Vfds Thermocouples And Transducers Extra Through These Inputs We Are Able To Optimally Control And Monitor The Vital Processes Within The Plant Environment This Product Is A 16 Channel Analog Input Module Designed With Galvanic Isolation Across Four Distinct Groups Each Comprising Four Channels
